WashWorld error codes?

[TechGuy]

I'm getting a Code 60 on my High Velocity. Every manual I have only shows codes up to 56. What is code 60? Thanks!!



[TechGuy]

I'm also getting errors 28 and 39, both of which don't exist in my manual. I'm in another universe!



[BBE]

60 is arch rotate failure IIRC. As for which prox switch it is specifically, I couldn't tell you off the top of my head, I'll look at my cheat sheet tomorrow and let you know if nobody has answered you first. Also 39 I know off the top of my head means that the wash has been out of service for at least 15 minutes. 28 I don't know off the top of my head, I'll look on my cheat sheet for that tomorrow too.



[whitescout]

Number 60 is prox number 5 is on when it should be off.
number 39 is wash out of service for 15 minutes.
Number 28 is main tank over fill. ( no input from fill sensor )



[TechGuy]

Thank you!! I thought that the problem was 5 was off when it should be on... (e.g. bad connection somewhere)... You just changed my whole thought process now. Any chance you can scan/upload your list? I guess I can just call WashWorld tomorrow and see if they can email me an updated manual. Thanks for your help!



[lag]

List of prox codes and quick explanation
60 Prox 5 turned on (should be off)

61 Prox 5 turned off (should be on)


62 Prox 6 turned on (should be off)

63 Prox 6 turned off (should be on)

64 Prox 7 turned on (should be off)

65 Prox 7 turned off (should be on



[JustClean]

Hey Washworld,
why not sending the error code in clear English? Saves everyone looking for a cheat sheet.
